Zhongda Leader 60ZDF Spur Precision Planetary Gearbox, 10:1
Zhongda Leader (ZD) · MPN 60ZDF, ratio 10 (exact code unknown) · Maglev ID ac-zd-60zdf-010
CN Maker in China, factory not confirmed unknown VERIFIED
Lower-cost Chinese spur-gear planetary for servo and stepper axes; 12 N·m rated, <8 arcmin.
Specifications
| Ratio | 10:1 |
|---|---|
| Rated output torque | 12 N·m |
| Backlash | <8 arcmin (1-stage) |
| Frame size | 60 mm |
| Stages | 1 |
Who makes it
MakerNingbo Zhongda Leader Intelligent Transmission Co., Ltd. (中大力德)
Based inChina
RoleBrand owner
Need a different shaft, connector, firmware or enclosure, or a price at 1,000 units? Maglev takes the catalog part to the factory and comes back with a custom version and one fixed price.
Landed cost in the US
Loading duty data…
Compliance
| HTS classification | 8483.40.50 |
|---|---|
| NDAA | unknown |
| Blue UAS | unknown |
| FCC | n/a |
Sources
- https://en.zd-motor.com/products_detail/420.htmlZDF technical data table
Record confidence: VERIFIED. VERIFIED means the maker's own documents; REPORTED means a credible third party; UNVERIFIED means a single weak source. Anything we could not confirm says unknown.
