ArmSoM CM5 (RK3576)
ArmSoM · Maglev ID cm-armsom-cm5-rk3576
CN Maker in China, factory not confirmed unknown VERIFIED
RK3576 compute module with LPDDR5 and optional WiFi 6, also sold as Banana Pi BPI-CM5 Pro; described in press as mostly CM4-pinout compatible.
Specifications
| SoC | Rockchip RK3576 |
|---|---|
| NPU | Up to 6 TOPS INT8 |
| Memory | 4GB LPDDR4x (Basic) or 8GB LPDDR5 (CM5 / Pro); SoC supports up to 16GB |
| Form factor | Compute module; connector not stated on maker page ('mostly compatible with the Raspberry Pi CM4 pinout' per Hackster, REPORTED) |
| Operating temp | 0 to 80 C |
| eMMC | 32GB listed |
Who makes it
MakerArmSoM
Based inChina
RoleBrand owner
Need a different shaft, connector, firmware or enclosure, or a price at 1,000 units? Maglev takes the catalog part to the factory and comes back with a custom version and one fixed price.
Landed cost in the US
CN
25%+?
TW
0%+?
VN
0%+?
IN
0%+?
JP
0%+?
KR
0%+?
DE
0%+?
MX
0%+?
US
0%
Total US duty on this part by where it is made (2026-10-29). Mexico shown before USMCA preference; qualifying goods enter duty free. Your factory choice, not the shipping port, sets the origin.
Loading duty data…
Compliance
| HTS classification | 8473.30.11.80 typical, not a ruling |
|---|---|
| NDAA | unknown |
| Blue UAS | unknown |
| FCC | n/a |
| Notes | US orders prepay 25% duty per ArmSoM store. |
Equivalents from other makers
Sources
- https://www.armsom.org/product-page/cm5specs, temp; prices CM5 8GB/32GB $192, Basic 4GB/64GB/WiFi $140, Pro 8GB/32GB/WiFi $199 (seen 2026-10-27, Maglev research); on 2026-10-29 the page text showed only a $36.00 headline price with no per-config prices
- https://www.hackster.io/armsom-jackson/armsom-cm5-compatible-alternative-to-raspberry-pi-cm4-01908cCM4 pinout claim (REPORTED)
Record confidence: VERIFIED. VERIFIED means the maker's own documents; REPORTED means a credible third party; UNVERIFIED means a single weak source. Anything we could not confirm says unknown.
