Elmo Gold Whistle 20/100 Servo Drive
Elmo Motion Control · Maglev ID mo-elmo-gold-whistle-20-100
IL Maker in Israel, factory not confirmed unknown VERIFIED
PCB-mount 55 x 46 mm Gold-family servo drive running from a single 12-95 V supply, 1.6 kW continuous in the 20/100 rating, with STO and EtherCAT/CANopen.
Specifications
| Bus voltage | 12-95 V (85 V nominal) |
|---|---|
| Continuous current | 20 A amplitude (14.1 A RMS) |
| Peak current | 2 x Ic = 40 A amplitude |
| Interface | EtherCAT, CANopen, Ethernet, RS232, USB |
| Feedback | Incremental, digital Hall, SIN/COS, resolver, BiSS, EnDat 2.2/3, HIPERFACE/DSL, SSI, Tamagawa, Panasonic, Sanyo Denki |
| Continuous power | 1600 W |
| Mass | 55 g |
| Dimensions | 55 x 46 x 15 mm |
| Safety | STO |
Who makes it
MakerElmo Motion Control
Based inIsrael
RoleBrand owner
Need a different shaft, connector, firmware or enclosure, or a price at 1,000 units? Maglev takes the catalog part to the factory and comes back with a custom version and one fixed price.
Landed cost in the US
CN
37.5%
TW
10%
VN
12.5%
IN
10%
JP
12.5%
KR
12.5%
DE
10%
MX
10%
US
0%
Total US duty on this part by where it is made (2026-10-29). Mexico shown before USMCA preference; qualifying goods enter duty free. Your factory choice, not the shipping port, sets the origin.
Loading duty data…
Compliance
| HTS classification | 8504.40.40.00 typical, not a ruling |
|---|---|
| NDAA | unknown |
| Blue UAS | unknown |
| FCC | n/a |
Equivalents from other makers
Works with
TQ-RoboDrive ILM50x08 Servo KitTQ-RoboDrive · DE · Quote
Kollmorgen KBMS-17H01-C Frameless Motor (with Halls) (winding C)Kollmorgen · US · Quote
maxon EC frameless DT 50 M, 54 mm, 210 Wmaxon · CH · $429.03
Celera Motion Omni+ OPH-060-013-B Frameless MotorCelera Motion (Novanta) · US · Quote
ThinGap LSI 75-20 Slotless Motor KitThinGap (Allied Motion) · US · Quote
maxon EC 45 flat 70 W, 24 V, Hall sensorsmaxon · CH · $204.12
maxon EC-i 40, 70 W, 36 V, Hall sensorsmaxon · CH · $343.44
Portescap 22ECS60 Ultra EC brushless slotless motor (coil 16)Portescap · US · QuoteSources
- https://www.elmomc.com/product/gold-whistle/model table, supply, current, feedback, interfaces, mass, dimensions, install guide + STEP links
Record confidence: VERIFIED. VERIFIED means the maker's own documents; REPORTED means a credible third party; UNVERIFIED means a single weak source. Anything we could not confirm says unknown.
